    Aluminum 2.4mil Multilayer Pcb Fabrication Led Bulb Circuit Board

    Ask Lasest Price
    Brand Name : BQZYX+
    Model Number : ZYX-2181XXCDF
    Certification : FCC
    Price : Negotiation
    Payment Terms : T/T, D/A, D/P, Western Union
    Supply Ability : 160000 Pieces per Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Aluminum 2.4mil Multilayer Pcb Fabrication Led Bulb Circuit Board

    Aluminum 2.4mil Multilayer Pcb Fabrication Led Bulb Circuit Board


    About us:
    Was founded in year of 2010 .With being OEM manufacturer specializing in PCB/PCBA Sensors etc with 11-year,nowadays,we have built up our strong product research and development center and we are devoting ourselves to electronics smart

    product. combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers one stop Service
    requirements – from front end engineering through to in time deliveries.
    PCB Service
    ZYX offers pcb production services from1~20Layer For Rigid,1~4Layer for flexible,1~16layer Rigid-Flex pcb.The materials includes standard FR4, High TG FR4,
    Aluminum,Polyimide and your Request !

    Components sourcing
    ZYX offers electronics components souring service ., All IC chips , transistors , crystals .… are new and original . The quality of all components can be assured after 10years experience ,High quality and Low cost

    Programming/ Function Testing
    ZYX offers programming and function testing services. HEX file and BiN file are available for IC program work by us. For The Function testing ,please prepare detailed testing instruction and documents or more detailed guide


    Model Number:

    ZYX-2181XXCDF

    Place of Origin:

    Shenzhen, China

    Base Material:

    aluminum

    Brand Name:

    BQZYX+

    Board Thickness:

    0.2~6mm

    Min. Line Spacing:

    0.15mm / 0.1mm/4mil or Custom

    Board Thickness:

    0.2~6mm

    Product Keywords:

    pcb for led bulbs,led tube light pcb,led segment pcb

    Min. Line Width:

    0.15mm / 0.1mm or Custom

    Copper Thickness:

    0.5-4OZ / 1 Oz / 2Oz or Custom


    1. PCB manufacturing
    Needed: Gerber file(main), .Pcb.Doc and KiCAD-PCB, etc.
    2. Components sourcing
    Needed: BOM list included detailed Part number and Designator.
    3. PCB assembly
    Needed:PCB file and BOM list.
    Our sales & engineer teams will reply you completely PCBA Quotation within 12 hours.
    PCB Making
    Layers: 1-58 layers
    (Main advantages from 2 layers, 4layers 6 layers, 8 layers hdi to 20layers.)
    Max.Thickness:
    HASL lead free is 0.6-4.0mm; ENIG is 0.2-7.0mm; Siliver: 0.4-5.0mm;
    Material: FR-4 TG170 TG180 in mass production
    (Shengyi S1141,S1165,S1600, IT180A,etc.)
    Min.Width/Spacing: 0.1mm in hdi, and 0.15-0.2mm for standard making.
    Max.Copper Thickness: 0.5oz-12oz heavy copper
    Min. Hole Size: Laser drill is 0.1mm-0.15mm | ±0.05mm (4-6mil±2mil)
    Max. Panel Size: 1150mmx560mm
    Aspect Ratio: 12:1 and 8:1 in mass production
    Surface Finish: HASL lead free,Immersion Gold, Immersion Silver mainly.
    Special Process:
    Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity,
    Hybrid, Partial hybrid, Partial high density, Back drilling and Impedance control.


    Layer

    1,2,4 or 6,upto 18 layers

    Material

    FR4,CEM1,CEM3,Hight TG,FR4 Halogen Free,FR1,FR2

    Order Quantity

    1-500,000

    Board shape

    Rectangular,round,slots,cutouts,complex,irregular

    Board type

    Rigid,flexible,rigid-flexible

    Board material

    FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc

    Board cutting

    Shear,V-score,tab-routed

    Board thickness

    0.2~4.0mm,Flex 0.01~0.25''

    Copper weight

    1.0,1.5,2.0oz

    Solder mask

    Double-sided green LPI,Also support red,white,yellow,blue,black

    Silk screen

    Double-sided or single-sided in white,yellow,black,or negative

    Silk screen min line width

    0.006'' or 0.15mm

    Max board dimensions

    20inch*20inch or 500mm*500mm

    Min drill hole diameter

    0.01'',0.25mm.or 10 mils

    Surface finish

    HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc

    Board thickness tolerance

    ± 10%

    Copper weight tolerance

    ± 0.25oz

    Minimal slot width

    0.12'',3.0mm,or 120mils

    V-score depth

    20-25% of board thickness

    Plated through holes

    Yes

    Sink holes

    Yes

    Design file format

    Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG


    FAQ

    Q. What service can you supply ?


    ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA inside the enclosure,Functiontesting and other value-added service.


    Q. What file you need to prepare if you want to get an quotation from us?


    For PCB board, you need to prepare files of Gerber file,it should including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.

    For PCBA(PCB with soldered components), except the file for PCB, you also need to prepare the BOM list (components list), Pick and Place file(txt format), real sample pictureor 3D PDF version file etc.


    Q. Do you have any MOQ Limited ?


    We havent any limited about MOQ .Sample and mass production all can support.


    Q. How to keep our product information and design file secret ?


    We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.


    Q. How long does it take for PCB and PCBA Quote ?


    PCBs quotation within 2 hours can finished the PCBA depend on the components

    quantity,if simple, within 6 hours can finished,once complex and more,the 12- 36 hours

    can be finished.

    *Please note that the following detail will speed up evaluation:

    Material:

    Board thickness:

    Copper thickness:

    Surface finish:

    Solder mask color:

    Silkscreen color:


    Q. How about the delivery?


    Normally, for sample order, our delivery is about 5 days.For small batch, our delivery is about 7 days.

    For mass production batch, our delivery is about 10 days.

    But that depends on the real condition when we get your order.

    If your order is urgently please contact us directly ,we will priority to deal it and do ourbest to give you satisfied delivery time.


    Q. How can we guarantee you receive an good quality product?


    For PCB, we will use Flying Probe Test, E-test etc. for it.

    For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.


    Q. With payment terms do we acc
